Basic Info.
Model NO.
tropical fish breeding aeration tube
Certification
RoHS, ISO
Outer Diameter
10 to 28 mm
Wall Thickness
2 mm Above
Dynamic Power
02 / Kw. Hr
Air Flow
3-12 Cubic Meters/Hrm
Applicable Water Depth
0-6 Meters
Transport Package
Standard Sea Worthy Package
Specification
ISO
Trademark
MW
Origin
China
HS Code
848390000
Production Capacity
100000m/Day
Product Description
1) tropical fish breeding aeration tube
2) Efficient increasing oxygen
3) Acid and alkali resistance, ageing resistance
aero tube ,aerotube for aeration system
Used to make the dissolved oxygen in the water reach higher amount and enhance the stocking density. Apply to aquaculture, sewage treatment, garden irrigation, greenhouse grow.
Tube
Rubber aeration tube
Cold resistance(-40°C,8h)
Tensile length ≥2.2 Mpa
Tensile elongation ≥130 percent
Hot empty aging (70°C 72h)
Tensile strength rate ≤20 percent
Break elongation rate ≤20 percent
Resist 5% NaOH (23°C 72h)
Tensile strength rate ≤20 percent
Break elongation rate ≤20 percent
Resist 5% HCl (23°C 72h)
Tensile strength rate ≤20 percent
Break elongation rate ≤20 percent
Pressure
s-1 200Kpa
(water seepage amount) 600-800ml/h.m
s-2 200Kpa
(water seepage amount) 10.8l/h.m
200Kpa increase Oxygen amount 420ml/h.m
Product performance parameters:
Outer Diameter: 10 to 28 mm
Wall thickness: 2 mm above
The bubble diameter: 20-50 um
Dynamic power: 02 / kw. Hr
The air flow: 3-12 cubic meters/HRM
Applicable water depth: 0-6 meters
Vortex air pump: effective water depth about 1 meter , housed density 1-2 times improve.
Centrifugal pump: effective water depth about 2-3 meters, stocking density improve 3-4 times.
Cottonwood ROM watts fan: effective 3-10 metres above water depth, the effective length can reach 300 m, stocking density can be reached 3-6 times.
Note: no matter you use which kinds of models of air pump, and the pipe section sum is not greater than the total area of main section. If the unclear place, can inquire!
2) Efficient increasing oxygen
3) Acid and alkali resistance, ageing resistance
aero tube ,aerotube for aeration system
Used to make the dissolved oxygen in the water reach higher amount and enhance the stocking density. Apply to aquaculture, sewage treatment, garden irrigation, greenhouse grow.
Tube
Rubber aeration tube
Cold resistance(-40°C,8h)
Tensile length ≥2.2 Mpa
Tensile elongation ≥130 percent
Hot empty aging (70°C 72h)
Tensile strength rate ≤20 percent
Break elongation rate ≤20 percent
Resist 5% NaOH (23°C 72h)
Tensile strength rate ≤20 percent
Break elongation rate ≤20 percent
Resist 5% HCl (23°C 72h)
Tensile strength rate ≤20 percent
Break elongation rate ≤20 percent
Pressure
s-1 200Kpa
(water seepage amount) 600-800ml/h.m
s-2 200Kpa
(water seepage amount) 10.8l/h.m
200Kpa increase Oxygen amount 420ml/h.m
Model | Outer Diameter(mm) | Wall thickness(mm) | Inside(mm) | Weight(g/m) | Meter/bundle |
| BA1015 | 10 | 1.5 | 7 | 45 | 200 |
| BA1425 | 14 | 2.5 | 9 | 90 | 200 |
| BA1630 | 16 | 3 | 10 | 115 | 200 |
| BA1835 | 18 | 3.5 | 11 | 150 | 200 |
| BA2035 | 20 | 3.5 | 13 | 160 | 100 |
| BA2140 | 21 | 4 | 13 | 200 | 100 |
| BA2240 | 22 | 4 | 14 | 205 | 100 |
| BA2540 | 25 | 4 | 17 | 240 | 100 |
| BA2550 | 25 | 5 | 15 | 295 | 100 |
| BA2560 | 25 | 6 | 13 | 310 | 100 |
| BA2570 | 25 | 7 | 11 | 335 | 100 |
| BA2840 | 28 | 4 | 20 | 290 | 100 |
| BA2860 | 28 | 6 | 16 | 340 | 100 |
Product performance parameters:
Outer Diameter: 10 to 28 mm
Wall thickness: 2 mm above
The bubble diameter: 20-50 um
Dynamic power: 02 / kw. Hr
The air flow: 3-12 cubic meters/HRM
Applicable water depth: 0-6 meters
Vortex air pump: effective water depth about 1 meter , housed density 1-2 times improve.
Centrifugal pump: effective water depth about 2-3 meters, stocking density improve 3-4 times.
Cottonwood ROM watts fan: effective 3-10 metres above water depth, the effective length can reach 300 m, stocking density can be reached 3-6 times.
Note: no matter you use which kinds of models of air pump, and the pipe section sum is not greater than the total area of main section. If the unclear place, can inquire!
